Foxconn H77MXV Series User Manual

PRODUCT INTRODUCTION
2
1-1 Product Specications
CPU Support IntelIvyBridge/SandyBridgeLGA1155Processors
Maxprocessorpowerupto95W
For the latest CPU information, please visit:
http://www.foxconnsupport.com/cpusupportlist.aspx
Chipset Intel
®
H77
Memory 2x240-pinDDR3DIMMs
Support up to 16GB of system memory
Dual channel DDR3 1600/1333/1066
Expansion Slots 1 x PCI Express x16 slot
2xPCIExpressx1slots
Storage Intel®H77chipset
-2xSATA2.0connectors(3Gb/sdatatransferrate)
-2xSATA3.0connectors(6Gb/sdatatransferrate)
SupportRAID0,1,5,10
LAN Realtek RTL8111F-CG Gigabit LAN controller
Support 10/100/1000Mbps
Audio RealtekALC662-GR
-HighDenitionAudio
-2/4/5.1-channel
-Support Jack-Sensing function
USB Supportupto8xUSB2.0ports(4rearpanelports,2onboardUSB
headerssupporting4extraports)
SupportUSB2.0protocolupto480Mb/s
Supportupto4xUSB3.0ports(2rearpanelports,1onboardUSB
headersupporting2extraports)
SupportUSB3.0protocolupto5Gb/s
Internal
Connectors
1x24-PinATXpowerconnector
1x4-pinATX12Vpowerconnector
1xCPUFANheader(4-pin)
1xSystemFANheaders(4-pin)
1 x Front panel header
1 x Front Audio header
1 x Speaker header
2xSATA3.0connectors
2xSATA2.0connectors
2xUSB2.0headers
1 x USB 3.0 header
1 x SPDIF OUT header
1 x TPM header
1 x LPT header
1 x CIR header
1 x INTR header
1 x COM1 header
1 x Clear CMOS header
