RAID CONFIGURATION
91
5. Recovery Volume Options
1. “Recovery Volume Options” is only available when “Recovery” is built. Here, we take
 TryRecoveryasanexample,select“4.RecoveryVolumeOptions”inmainmenuandpress
<Enter>. The screen displays:
Intel(R)MatrixStorageManageroptionROMv5.0.0.1011ICH9RwRAID5
Copyright(C)2003-04IntelCorporationAllRightsReserved.
1. Enable Only Recovery Disk
 2.EnableOnlyMasterDisk
Enable Only Recovery Disk - enables recovery disk if avaliable and
disables master disk.
Enable Only Master Disk - enables master disk if avaliable and
disables master disk.
Actions will result in change from Contious Update mode to On-Request.
Intel(R)RapidStorageTechnology-UptionROM-11.0.8.1204
Copyright(C)2003-11IntelCorporation.AllRightsReserved.
[↑↓]-Select[ESC]-Exit[ENTER]-SelectMenu
[ HELP ]
[ RECOVERY vOLUME OPTIONS ]
1. Enable Only Recovery Disk
2.UseUporDownkeytomakeaselectiontoenableRecoveryorMasterdisk.
3. Here, we select “1.Enable Only Recovery Disk“ and press<Enter> to continue. The screen
display:
Intel(R)MatrixStorageManageroptionROMv5.0.0.1011ICH9RwRAID5
Copyright(C)2003-04IntelCorporationAllRightsReserved.
1. Enable Only Recovery Disk
 2.EnableOnlyMasterDisk
Enable Only Recovery Disk - enables recovery disk if avaliable and
disables master disk.
Enable Only Master Disk - enables master disk if avaliable and
disables master disk.
Actions will result in change from Contious Update mode to On-Request.
Intel(R)RapidStorageTechnology-UptionROM-11.0.8.1204
Copyright(C)2003-11IntelCorporation.AllRightsReserved.
1. Enable Only Recovery Disk
[↑↓]-Select[ESC]-Exit[ENTER]-SelectMenu
[ HELP ]
[ RECOVERY vOLUME OPTIONS ]
Name Level Capacity Status Bootable
TryRecovery Recovery(Cont.) 74.5GB Normal Yes
Select a Recovery volume to do the operation.
[↑↓]-Up/Down[SPACE]-Selects[ENTER]-Done
[ SELECT RECOVERY VOLUME]
TryRecovery Recovery(Cont.) 74.5GB NormalYes
