Foxconn H77MXV Series User Manual

RAID CONFIGURATION
90
Intel(R)MatrixStorageManageroptionROMv5.0.0.1011ICH9RwRAID5
Copyright(C)2003-04IntelCorporationAllRightsReserved.
  1.CreateRAIDVolume  4.RecoverVolumeOptions
  2.DeleteRAIDVolume  5.AccelerationOptions
3. Reset Disks to Non-RAID 6. Exit
RAID Volume :
ID Name Level Stripe Size Status Bootable
 0 TryRAID5  RAID5(Parity)64KB 149.1GB Normal Yes
Physical Disks:
Port Drive Model Serial # Size Type/Status(Vol ID)
 0 HitachiHDS72161 PVF904Z21G2JZM 149.0GB Member Disk(0)
1
ST380811AS 5PS1TAGW 74.5GB Member Disk(0)
 2
SAMSUNG HD161HJ  S0V3J9APA30524 149.0GB Non-RAID Disk
3
ST380815AS 5RW1CA37  74.5GB Non-RAID Disk
Intel(R)RapidStorageTechnology-UptionROM-11.0.8.1204
Copyright(C)2003-11IntelCorporation.AllRightsReserved.
[DISK/VOLUMEINFORMATION ]
[ MAIN MENU ]
[↑↓]-Select[ESC]-Exit[ENTER]-SelectMenu
"Degraded"volumeanddiskavailableforrebuildingdetected.Selecting
a disk initiates a rebuild. rebuild completes in the operating system.
Select the port of the destination disk for rebuilding (ESC to exit):
Port Drive Model Serial # Size
2SAMSUNGHD161HJ S0V3J9APA30524 140.9GB
  3ST380815AS  5RW1CA37 74.5GB
[ DEGRADED VOLUME DETECTED ]
3ST380815AS  5RW1CA37  74.5GB
[↑↓]-Previous/Next[ENTER]-Select[ESC]-Exit
5.ItgoesbacktoMainmenuwitha"Rebuild"statusofRAID5volume.Eventually,areplace-
 mentharddiskhastojoininanditalwayskeepsthreeharddisksintheRAID5system.
6. Operating System will perform the rebuilding later.
Intel(R)MatrixStorageManageroptionROMv5.0.0.1011ICH9RwRAID5
Copyright(C)2003-04IntelCorporationAllRightsReserved.
  1.CreateRAIDVolume  4.RecoveryVolumeOption
  2.DeleteRAIDVolume  5.AccelerationOptions
6. Exit
RAID Volume :
ID Name Level Stripe Size Status Bootable
 0 TryRAID5  RAID5(Parity)64KB 149.1GB Rebuild Yes
Physical Disks:
Port Drive Model Serial # Size Type/Status(Vol ID)
 0 HitachiHDS72161 PVF904Z21G2JZM 149.0GB Member Disk(0)
1
ST380811AS 5PS1TAGW 74.5GB Member Disk(0)
 2
SAMSUNG HD161HJ  S0V3J9APA30524 149.0GB Non-RAID Disk
3
ST380815AS 5RW1CA37  74.5GB Member Disk(0)
Volume with “Rebulid” status will be rebuilt within the operating system.
Intel(R)RapidStorageTechnology-UptionROM-11.0.8.1204
Copyright(C)2003-11IntelCorporation.AllRightsReserved.
[DISK/VOLUMEINFORMATION ]
[ MAIN MENU ]
3. Reset Disks to Non-RAID
[↑↓]-Select[ESC]-Exit[ENTER]-SelectMenu
