25 | P a g e
3 ON ON OFF OFF 11 ON ON OFF ON
4 OFF OFF ON OFF 12 OFF OFF ON ON
5 ON OFF ON OFF 13 ON OFF ON ON
6 OFF ON ON OFF 14 OFF ON ON ON
7 ON ON ON OFF 15 ON ON ON ON
NOTE: Unlike the TX-200 transmitter, the TX-505 will not be able to
control FOXPRO
®
units such as the FX3, FX5, Scorpion, etc.
6.14 FOXBANG
TURNING FOXBANG ON OR OFF
1. Access the Main Menu on your TX-505 (while powered on, press and
hold the rotary selector knob down for 3-5 seconds to bring up the
menu). Use the selector knob to highlight the FOXBANG/FOXGRIP
menu item and press down on the rotary selector knob a single time to
access the options menu.
2. To turn on FOXBANG, enter the FOXBANG OPTIONS menu and then
select the desired feature that you would like FOXBANG to engage. To
turn off FOXBANG, select the FOXBANG OFF option from the menu.
NOTE: When FOXBANG is turned on and your sensitivity rating set, the
TX-505 will remember the sensitivity setting and FOXBANG will
automatically be activated the next time you perform a power cycle. If you
do not wish to have FOXBANG active the next time you turn on the TX-
505, you must go into the FOXBANG menu item and turn it off.
FOXBANG OPTIONS
FOXBANG can be setup to activate one of four possible features. You can
have it emulate an auxiliary button press, activate preset 1 or 2, or toggle mute
status. The mapped function for FOXBANG is established by selecting the
appropriate option from the FOXBANG OPTIONS menu.
SELECTING YOUR SENSITIVITY
Your TX-505 has 5 sensitivity ratings; Highest, High, Medium, Low, and
Lowest. From the Main Menu on your TX-505, select the FOXBANG item and
the select the FOXBANG ADJUST menu item (see image below). Highlight the
desired sensitivity rating and press down on the rotary selector knob to set it. If
you are using a large caliber (.30-06), you would want to select a lower
sensitivity. If using a smaller firearm (such as .17HMR or .22), use the higher
