Franke HCMF-18 User Manual

HCMF Operating Manual Page 19
8 Unit Specifications
Model HCMF Series – High Capacity Meat Freezers
The HCMF is a compact, custom freezer designed for short-term grill-side storage of
frozen hamburger patties and secondary grilled product, providing quick and easy
access at point-of-use. Designed to be positioned immediately adjacent to the Grill
Station, the HCMF is available in two sizes, 18-inches wide and 30-inches wide, with a
front case-loading door and an insulated, automatic roll-back top lid that provides quick
access with minimum exposure of frozen product. HCMF Models have the following
specifications and utility requirements:
* NOTE: 18005519 has the condenser mounted top-right. Use Part No. 18005056
for condenser factory-mounted top-left.
Key Performance Specifications
Product Model:
HCMF-18
HCMF-30
Part Number:
18005560
18005519*
Capacity: Cubic Feet
6.8
13.1
Capacity: Burgers
3 box
6 boxes
Refrigeration/Type:
Forced air cooling system using R-404A Refrigerant
Agency Listings:
CULUS & NSF
CULUS & NSF
Key Dimensions & Weights
Unit Width:
18” (458 mm)
30.86” (784 mm)
Unit Depth [front-to-back]:
37” (940 mm)
37” (940 mm)
Unit Height
54.77” (1391 mm)
54.77” (1391 mm)
Minimum Door Swing
+22” (to depth)
+32” (to depth)
Shipping Weight
337 lbs.
427 lbs.
Unit Operating Weight
265 lbs.
365 lbs.
Electrical/Utility Requirements
Voltage [VAC]
120 VAC
120 VAC
Phase [PH]
1-phase
1-phase
Cycles [Hz]
60 Hz
60 Hz
Amperage [AMP]
7 AMPs
10 AMPs
Watts
840
1200
Power Cord Provided
Yes
Yes
Plug Provided
Straight Blade
Straight Blade
Installation/Operating Conditions/Requirements
Max. Room Temp.
82 F
82 F
Max. Room Humidity
60%
60%
Min. Side Clearance
0” (2” recommended)
0” (2” recommended)
Min. Rear Clearance
1” (2” recommended)
1” (2” recommended)

Franke HCMF-18 Specifications

General

Brand	Franke
Model	HCMF-18
Category	Freezer
Language	English
