HCMF Operating Manual Page 8
6 Install Glove Dispenser Bracket
(Medium Phillips Screwdriver Required)
 Remove glove dispenser bracket
and two mounting screws from
padded envelope.
 Position glove dispenser over
mounting holes on the top edge of
the front product-loading door.
Make sure holes align and the two
glove package-hanging studs face
forward.
 Using a Phillips screwdriver, screw in the two self-tapping
mounting screws until the bracket is secure.
7 Position, Provide Enough Space & Plug in Unit
 The HCMF can be positioned on either side of the grill
station. The typical grill station line-up is as follows:
Grill Station
 Provide the following clearance from walls and other
equipment:
Model
Side Clearance
Rear Clearance
Front & Top
Clearance
Minimum
Rec.
Minimum
Rec.
HCMF-18
0”
2”
1”
2”
Keep Open
HCMF-30
0”
2”
1”
2”
Keep Open
HCMF
(left)
HCMF
(right)
