FP4000 Rev0204

Program Access Mode

When in the program access mode the digital display will show operator inputs,

program options, and error codes. To gain access to the program features a three digit

program code must be entered. Review the Program Code Descriptions or refer to

Table 2. Program Code Quick Reference for the proper three digit code.

Note: There is a timeout feature that will return the program to normal

operation in three seconds if an input is not detected at the magnet sensors.

Select Program Access Mode

Touch a small magnet on the glass at the M3 sensor and hold it there until the

display shows four dashes. The program access mode is ready for a program code

number to be entered. (Refer to Figure 8.)

Enter Program Code Number

1. Select the Program Access Mode (four dashes are shown in the display).

2. Touch the magnet on the glass at the M1 sensor and remove it. The display

will show the number 100 and the first digit 1 will flash. Each time the magnet

is touched at the M1 sensor the number will scroll up by 1. Set the first digit to

the number desired.

3. Touch the magnet on the glass at the M2 sensor and remove it. The second

digit shown in the display will flash. Each time the magnet is touched at the

M2 sensor the number will scroll up by 1. Set the second digit to the number

desired.

4. Touch the magnet on the glass at the M1 sensor and remove it. The third digit

shown in the display will flash. Each time the magnet is touched at the M1

sensor the number will scroll up by 1. Set the third digit to the number desired.

When a valid three digit program code is entered the display will show a program

value or an option. If an invalid code is entered the display will show an error code.

Note: When a valid code has been entered and the display shows a program

value or an option, the timeout feature is disabled.

Change Values or Options

Touch the magnet on the glass at the M1 sensor and remove it to select the digit to

be changed. The digit will flash. Touch the magnet on the glass at the M2 sensor and

remove it to change the digit or the option choice.

Exit Program Access Mode

Touch the magnet on the glass at the M3 sensor and hold it there until the display

shows four dashes. Remove the magnet and enter a new code or after 3 seconds the

program will timeout return to normal operation.

FRC Insight Ultimate Series User Manual
