Table 2. Program Code Quick Reference
• Refer to Program Code Descriptions for detailed information.
• There is a timeout feature that will return the program to normal operation in
three seconds if input is not detected at the magnet sensors.
• When a valid code has been entered and a programed value or option is shown
in the display, the timeout feature is disabled.
Note: The sensors are activated by placing the north pole of a small magnet
on the glass in close proximity to the sensor and then moving it 1-inch
away. This produces an electronic signal that is similar to a button being
released. If the digits in the display do not change try moving the magnet
further away from the sensor or turn the magnet around (the south pole
will not work).
CODE
FEATURE OPTIONS
311
Flow Rate Increment
Increments by 10 at Flow Rates
Above Program Setting
Increments by 1 at Flow Rates
Below Program Setting
312
ID Number 0 to 99
313
Module Function Pri, SLA
315
High Flow Warning 0 to 9999
0 = Disabled
316
Low Flow Warning 0 to 9999
0 = Disabled
317
Totalizer Reset YES = Resets to 0 at power on
no = Stores Total Flow at power off
318
Flow Cutoff (Frequency) 0 to 99.9
319
Flow Cutoff (Flow Rate) 0 to 999
321
Flow Calibration (Single Point) Calibrate at 1 Flow Rate
322
Flow Calibration (Multiple Point) Calibrate at 2 to 10 Flow Rates
323
Pressure Calibration Calibrate at 2 to 5 Pressure Levels
E202
Invalid Code Was Entered Re-enter Code
E204
No Flow Sensor Signal Check Water Flow and Wiring
E206
Invalid Calibration Point Select Different Calibration Point
E208
Memory Failure Contact FRC
