FP4000 Rev0204
26
Code 316 Low Flow Warning
Factory programmed value:0 (Low flow warning is disabled.)
Options: 0001 to 9999
This code will allow the low flow rate warning to be set. When the flow rate is
below the low flow warning program value, the flow display will alternately flash
between the flow rate and -LO- .
Code 317 Totalizer Reset
Factory programmed value:
Options: YES, no
This code will toggle the flow totalizer reset function on and off. The totalizer
reset function has two program settings YES and no. For the reset function to work the
totalizer reset is set to YES. Flow total will reset and start from 0 when power is
applied to the display module. If the optional totalizer buton is installed flow total will
reset to 0 when the total button is pressed and held. When the totalizer reset is set to no,
the flow total will accumulate and will not reset to 0 even when power is off.
Code 318 Flow Cutoff (Frequency)
Factory programmed value:
Options: 0 to 99.9 Hz
This code allows a cutoff frequency for the flow sensor to be set. There is always
some turbulence in the pipe that could cause the flow sensor to turn with the discharge
closed. This would cause the display to show a flow rate when there is no true flow.
The flow cutoff function is set so that the flow display will show 0 when the signal
from the flow sensor is below the programmed value.
Code 319 Flow Cutoff (Flow Rate)
Factory programmed value:
Options: 0 to 999
This code allows a cutoff flow rate for the flow sensor to be set. There is always
some turbulence in the pipe that could cause the flow sensor to turn with the discharge
closed. This would cause the display to show a flow rate when there is no true flow.
The flow cutoff function is set so that the flow display will show 0 when the signal
from the flow sensor is below the programmed value.
Code 321 Flow Calibration (Single Point)
Factory programmed value:Precalibrated to Pipe Size
Options: 1 Calibration Point
Refer to Calibration section.
