5
Notice: Do not get through power before complete assembly
Step 1:
Step 2:
Step 3:
1. Open the carton, get out the above
spare parts, and put the Main Frame
on the level ground.
2.Use the Phillips screwdriver (81) to
remove the screw ST4.2*20（116）；
3.Use the 8#Allen wrench (79) to
remove the bolt M10*20 (106) and the
spring washer (126)，and remove the L
shape board （ G ）， fasten the bolt
M10*20 (106) and spring washer (126)
by using the 8#Allen wrench (79)。
Notice：After you finish above steps,
the machine will look like step 2.
1.Lift up the left and right motor side
covers (13 、 14) by using Phillips
screwdriver (81) and ST4.2*12 screw
(96).
put the Main Frame on the level
ground.
