Fluids and Lubricants
See Table 20.6 for fluid and lubricant specifications.
Fluid and Lubricant Specifications
Component Recommended Fluid or Lubricant
Front Axle Spindle Pins, Tie Rods, Drag Link,
Intermediate Steering Shaft, Front Brake and
Pedal Shafts, Slip Spline and Universal Joints
Multipurpose Grease Lithium 12- Hydroxy Stearate NLGI No. 2; for
temperatures below 0°F (–18°C), use MIL-G-10924B
Hydraulic Brake Master Cylinder Heavy-Duty DOT 3 Brake Fluid
Brake and Pedal Pivots Starplex 2 (lithium soap-based grease)
Engine See Manufacturer’s Recommendations
Transmission Mobil Delvac Synthetic ATF
Fuel Ultralow-Sulfur Diesel Fuel
HD5 Grade Propane
Disc Brake Caliper Rails FCCC No. 4JD623 Brake Caliper Slide Grease
Rear Axle Differential See Manufacturer’s Recommendations
Hydraulic System Reservoir ATF must meet Dexron® III or TES-389 specifications
Engine Coolant 50% Water/50% Ethylene Glycol Antifreeze
Chevron Delo Antifreeze No. 275110 (propane engines only)
Table 20.6, Fluid and Lubricant Specifications
Fuse Information
See Table 20.7 for descriptions of a typical set of
fuses. Fuse identification varies with options.
Main PDM Fuse Identification
CAV Description Fuse
F1 Engine VCU (spare) 10A
F2 Blower Motor 30A
F3 Engine ECU 20A
F4 Spare —
F5 Ignition Switch 5A
F6
Hydro-Max RLY (if equipped with
hydraulic brakes)
30A
F7 Bulkhead Module 30A
F8 ICU3 10A
F9 Transmission ECU 10A
F10 Spare —
F11 Spare —
F12 Radio/Diagnostic 20A
F13 Chassis Module 30A
F14 Spare —
F15 Bulkhead Module 30A
F16 ABS ECU 25A
F17 Chassis Module 30A
Main PDM Fuse Identification
CAV Description Fuse
F18 Bulkhead Module 30A
F19 Chassis Module 30A
F20 Bulkhead Module 30A
F21 Spare —
F22 Bulkhead Module 30A
F23 Spare —
F24
Hydraulic Pump and RLY (if equipped
with hydraulic brakes)
25A
F25 Spare —
F26 Spare —
Table 20.7, Main PDM Fuse Identification
Specifications
20.5
