"EL" SERIES PARTS LIST
REF. PART NO. DESCRIPTION APPLICATION
EEE
LLL
223
443
JJJ
333
555
ELECTRICAL PARTS AA
31
1 617-166-06 Compressor, LGE, 230V, 60 Hz, 1 Ph, Model LGRC-990123-015 .. 1
1 611-935-47 Compressor, Tecumseh, 230V, 60 Hz, 1 Ph, Model AWF5524EXN 1
1 618-187-02 Compressor, Bristol, 230V, 60 Hz, 1 Ph, Model H25B355QABCC . 1
2 610-714-85 Motor, Fan .................................................................................... 1 1
2 610-714-84 Motor, Fan .................................................................................... 1
3 605-000-55 Cord, Electric Assembly - 30 Amp, 250 Volt ................................. 1 1 1
4 606-072-04 Switch, System - 8 Position.......................................................... 1 1 1
5 618-061-00 Switch, Rocker (Yes-No) ............................................................... 1 1 1
6 618-224-00 Thermostat (Cool & Heat) ............................................................. 1 1 1
7 610-803-51 Capacitor - 30/7.5 MFD, 400 V ...................................................... 1
7 610-803-56 Capacitor - 35/7.5 MFD, 400 V ...................................................... 1
7 610-803-33 Capacitor - 45/10.0 MFD, 370 V .................................................... 1
8 618-080-01 Resistor Block - 230 Volt .............................................................. 1 1 1
9 618-786-02 Heater Element - 5.5 KW .............................................................. 1 1 1
* 618-214-02 Wire Harness, Fan Motor .............................................................. 1
* 618-208-00 Wire Harness, Fan Motor .............................................................. 1 1
* 618-211-00 Wire Harness, Compressor ........................................................... 1 1
* 618-210-00 Wire Harness, Compressor ........................................................... 1
* 615-963-01 Fuse Link ..................................................................................... 1 1 1
* 618-279-00 Heater Limit .................................................................................. 1 1 1
REFRIGERATION SYSTEM COMPONENTS
10 618-500-03 Coil, Evaporator ............................................................................ 1 1
10 618-500-04 Coil, Evaporator ............................................................................ 1
11 618-502-09 Coil, Condenser ............................................................................ 1 1
11 618-502-02 Coil, Condenser ............................................................................ 1
* 03760473 Capillary Tube - .059 I.D. X 28½" - 30" Long .................................. 2 2
* 03760545 Capillary Tube - .042 x 20" Long .................................................... 5
* 614-813-01 Filter Drier (Install during sealed system repair) ............................ 1 1 1
CHASSIS PARTS
12 618-135-01 Shield, Bottom .............................................................................. 1 1
12 618-135-02 Shield, Bottom .............................................................................. 1
* 618-219-00 Shield, Side .................................................................................. 1 1 1
13 618-189-00 Bracket, Heater Mounting ............................................................. 1 1 1
14 614-939-05 Knob, Control ................................................................................ 2 2 2
15 618-069-00 Panel, Control Mounting ................................................................ 1 1 1
* 600-713-11 Bushing, Snap .............................................................................. 1 1 1
* 600-713-12 Bushing, Snap .............................................................................. 1 1 1
16 618-176-00 Panel, Left Side ............................................................................ 1 1 1
17 618-070-01 Partition, Control Box.................................................................... 1 1 1
18 618-204-00 Bracket, Capacitor Mounting......................................................... 1 1 1
19 618-207-00 Strap, Capacitor............................................................................ 1 1 1
* Not Shown
