SPECIFICATIONS
Friedrich Indoor Model Number Unit FSHSW09A1A FSHSW12A1A FSHSW18A3A FSHSW24A3A FSHSW36A3A
Friedrich Outdoor Model Number FSHSR09A1A FSHSR12A1A FSHSR18A3A FSHSR24A3A FSHSR36A3A
Outdoor Unit
Compressor Manufacturer
ZHUHAI LANDA COM-
PRESSOR CO.,LTD
ZHUHAI LANDA COM-
PRESSOR CO.,LTD
ZHUHAI LANDA COM-
PRESSOR CO.,LTD
ZHUHAI LANDA COM-
PRESSOR CO.,LTD
ZHUHAI LANDA COM-
PRESSOR CO., LTD
Compressor Model QXA-A091zE190 QXA-A091zE190 QXA-B141zF030A QXA-B141zF030A QXAS-D32ZX090A
Compressor Oil FVC68D or RB 68EP FVC68D or RB 68EP RB68EP RB68EP RB68EP or equivalent
Compressor Type Rotary Rotary Rotary Rotary Rotary
Compressor LRA. A 40 40 25 25 67
Compressor RLA A 12.62 15.23 12.08 12.18 17.5
Compressor Power
Input
W 980 980 1440 1440 4150±3%
Compressor Overload Protector
1NT11L-6233
or KSD115 or
HPC115/95U1
1NT11L-6233
or KSD115 or
HPC115/95U1
/ / 1NT11L-6233
Fan Type Axial-ow Axial-ow Axial-ow Axial-ow Axial-ow
Fan Diameter inch 15.748 15.748 / 20 21.654
Fan Motor Speed rpm 850 900 800 800 890
Fan Motor Power
Output
W 30 30 60 60 170
Fan Motor RLA A 0.24 0.23 0.52 0.4 0.73
Outdoor Unit Air
Flow Volume
m3/h 1800 1800 3200 3200 4400
Condenser Form
Aluminum Fin-copper
Tube
Aluminum Fin-copper
Tube
Aluminum Fin-copper
Tube
Aluminum Fin-copper
Tube
Aluminum Fin-copper
Tube
Condenser Pipe
diameter
inch 0.276 0.276 / / φ3/8
Condenser Rows-n
Gap
mm 1-1.4 2-1.4 1-1.4 2-1.4 2-1.4
Condenser Rows-n
Gap
inch 1-1/18 2-1/18 / / 2-1/18
Condenser Coil
Length (L×D×W)
inch 29 3/4×3/4×20 28×1 1/2×20 / / 37×1 3/4×30
Permissible Excessive
Operating Pressure for
the Discharge Side
MPa 4.3 4.3 4.3 4.3 4.3
Permissible Exces-
sive Operating
Pressure for the
Suction Side
MPa 2.5 2.5 2.5 2.5 2.5
Maximum Allowable
Pressure
MPa 4.3 4.3 4.3 4.3 4.3
Cooling Operation
Ambient Tempera-
ture Range
°F 0~115 0~115 0φ115 0~115 0~115
