Friedrich FSHW091 User Manual

151 PB
PARTS CATALOG
12k Indoor Unit
FIGURE 902
ITEM PART NUMBER PART DESCRIPTION USED ON MODEL QTY
1 69700659 300022 ‑ Front Panel Assy FSHSW12A1A 1
2 69700628 30565260 ‑ Display Board FSHSW12A1A 2
3 69700661 200022 ‑ Front Case Assy FSHSW12A1A 1
4 69700662 26112436 ‑ Helicoid Tongue FSHSW12A1A 1
5 69700631 10512037 ‑ Left Axile Bush FSHSW12A1A 1
6 69700664 100093 ‑ Rear Case assy FSHSW12A1A 1
7 69700665 5230014 ‑ Drainage Hose FSHSW12A1A 1
8 69700666 26152022 ‑ Ring of Bearing FSHSW12A1A 2
9 69700635 7651205102 ‑ O‑Gasket sub‑assy of
Bearing
FSHSW12A1A 2
10 69700668 24212179 ‑ Evaporator support FSHSW12A1A 1
11 #N/A #N/A FSHSW12A1A 1
12 69700670 100297601 ‑ Evaporator Assy FSHSW12A1A 1
13 69700333 1252484 ‑ Wall Mounting Frame FSHSW12A1A 1
14 69700672 10352056 ‑ Cross Flow Fan FSHSW12A1A 1
15 69700673 1501214605 ‑ Fan Motor FSHSW12A1A 1
16 69700642 2611216401 ‑ Connecting pipe clamp FSHSW12A1A 1
17 69700481 76712012 ‑ Rubber Plug (Water Tray) FSHSW12A1A 1
18 69700676 1521210710 ‑ SteppingMotor FSHSW12A1A 1
19 69700358 73012005 ‑ Crank FSHSW12A1A 1
20 69700678 10000204444 ‑ Electric Box Assy FSHSW12A1A 1
21 69700647 10542036 ‑ Axile Bush FSHSW12A1A 1
22 69700130 42011233 ‑ Terminal Board FSHSW12A1A 1
23 69700681 4202021906 ‑ Jumper FSHSW12A1A 1
24 69700650 300002000307 ‑ Main Board FSHSW12A1A 1
25 69700651 140206501 ‑ Electric Box Cover Sub‑
Assy
FSHSW12A1A 1
26 69700652 1592150 ‑ Shield Cover of Electric Box
Cover
FSHSW12A1A 1
27 69700653 2011220701 ‑ Electric Box Cover FSHSW12A1A 1
28 #N/A #N/A FSHSW12A1A 1
29 #N/A #N/A FSHSW12A1A 1
30 #N/A #N/A FSHSW12A1A 1
31 69700657 305001000085 ‑ Remote Controller FSHSW12A1A 1
32 69700690 409000004 ‑ Checking Panel Assy FSHSW12A1A 1
‑ITEMS ARE NON‑ ILLUSTRATED
*ITEMS ARE NON‑STOCKED, WILL NORMALLY REQUIRE 2‑3 WEEKS LEAD TIME
