Friedrich FSHW091 - Operation Characteristics Curve

19 PB
SPECIFICATIONS
Figure 205
36K Operation Characteristics curve
Cooling
Heating
24K
0
2
4
6
8
10
12
14
0 02 001
120
0
2
4
6
8
10
12
14
0 02 100 120
Conditio
n
Indoor:DB 80°F
WB66 °F
Indoor air flow: Super High
Pipe length:24 39/64ft
Condition
Indoor:DB 70°F
Indoor air flow: Super High
Pipe length:24 39/64ft
Current(A)
40 60 80
Compressor Frequency(Hz)
Current(A)
40 60 80
Compressor Frequency(Hz)
