Friedrich FSHW091 - 9-12 K Outdoor Unit Dimensions

26 PB
SPECIFICATIONS
Figure 227
9-12K Outdoor Unit Dimensions
Figure 226
36K indoor Unit Dimensions
53 9/64
12 53/64
10
11 19/32
3 1/2
1 37/64
13 25/32 1029 3/8
Φ2 3/4
Φ2 3/4
Unit: “ (inches)
21 1/4
11 1/4
30
10
12 5/8
33 3/8
21 1/4
Unit: “ (inches)
