Friedrich FSHW091 - Outdoor Unit

161 PB
Figure 907
ITEM PART NUMBER PART DESCRIPTION USED ON MODEL QTY
1 69700000 1473012 ‑ Front Grill FSHSR12A1A 1
2 69700772 153304901 ‑ Front Panel Assy FSHSR12A1A 1
3 69700773 10333004 ‑ Axial Flow Fan FSHSR12A1A 1
4 69700774 1501308507 ‑ Fan Motor FSHSR12A1A 1
5 69700808 0120388103P ‑ Chassis Sub‑assy FSHSR12A1A 1
6 #N/A #N/A FSHSR12A1A 1
7 69700777 76710302 ‑ Compressor Gasket FSHSR12A1A 1
8 69700268 103862 ‑ Compressor and Fittings FSHSR12A1A 1
9 69700812 30026000185 ‑ Electric Expansion
Valve Sub‑Assy
FSHSR12A1A 1
10 69700780 2012300101 ‑ Valve Cover FSHSR12A1A 1
11 69700814 7130239 ‑ Cut off Valve FSHSR12A1A 1
12 69700010 7100005 ‑ Valve FSHSR12A1A 1
13 69700011 1713041 ‑ Valve Support FSHSR12A1A 1
14 69700276 02123014P ‑ Cable Cross Plate 2 FSHSR12A1A 1
15 69700785 02123013P ‑ Cable Cross Plate 1 FSHSR12A1A 1
16 69700786 13030713 ‑ Right Side Plate Assy FSHSR12A1A 1
17 69700787 1413069 ‑ Cover of Pass Wire FSHSR12A1A 1
18 69700788 4300876701 ‑ Electric Expand Valve
Fitting
FSHSR12A1A 1
19 69700822 3900030903 ‑ Temperature Sensor FSHSR12A1A 1
20 69700790 3073403 ‑ 4‑Way Valve Assy FSHSR12A1A 1
21 69700213 4300040021 ‑ Magnet Coil FSHSR12A1A 1
22 69700792 180030 ‑ Compressor Overload
Protector(External)
FSHSR12A1A 1
23 69700274 1473057 ‑ Rear Grill FSHSR12A1A 1
24 69700827 11002000466 ‑ Condenser Assy FSHSR12A1A 1
25 69700795 1233034 ‑ Clapboard Sub‑Assy FSHSR12A1A 1
26 69700796 5106001201 ‑ Top Cover Sub‑Assy FSHSR12A1A 1
27 #N/A #N/A FSHSR12A1A 1
28 69700027 260309601 ‑ Electric Box Cover Sub‑
Assy
FSHSR12A1A 1
29 69700832 300027000325 ‑ Main Board FSHSR12A1A 1
30 69700833 100002061852 ‑ Electric Box Assy FSHSR12A1A 1
31 69700803 42010255 ‑ Terminal Board FSHSR12A1A 1
‑32 69700834 100002001751 ‑ Electric Box Assy FSHSR12A1A 1
‑33
#N/A #N/A FSHSR12A1A
0
‑ITEMS ARE NON‑ ILLUSTRATED
*ITEMS ARE NON‑STOCKED, WILL NORMALLY REQUIRE 2‑3 WEEKS LEAD TIME
PARTS CATALOG
12k Outdoor Unit
