14
Dimensions (W x H):
27” x 55 3/4”
Dimensions (W x H):
24 5/8” x 30 7/8”
Wall Opening Dimensions
NOTE: The distance between the rough opening and
the nished oor/platform must be 1”.
1”
Return Air Access Door Wall Cut-Out
27”
55 3/4”
Exterior Wall Plenum Cut-Out
