Friedrich VERT-I-PAK Series User Manual

5
Electrical Specications
Electrical Requirements
Wire Size Use ONLY wire size recommended for
single outlet branch circuit.
Fuse/Circuit
Breaker
Use ONLY type and size fuse or HACR cir-
cuit breaker indicated on unit’s rating guide.
Proper over current protection to the units is
the responsibility of the owner.
Grounding Unit MUST be grounded from branch
circuit to unit, or through separate ground
wire provided on permanently connected
units. Ensure that branch circuit or general
purpose outlet is grounded.
Wire Sizing Use recommended wire size given in tables
and install a single branch circuit. All wiring
must comply with local and national codes.
NOTE: Use copper conductors only.
WARNING
Electrical Shock Hazard.
Turn OFF electric power before service or instal-
lation.
Unit must be properly grounded.
Unit must have correct fuse or circuit breaker pro-
tection. Unit’s supply circuit must have the correct
wire conductor size. All electrical connections and
wiring must be installed by a qualied electrician
and conform to the National Electrical Code and all
local codes which have jurisdiction. Failure to do so
can result in property
damage, personal injury and/or death.
Vert-I-Pak
Family
Model
Number
Total
Refrigeration
Amps
Total Electric
Heat Amps
Electric
Heat Watts
Electric
Heat
Amps
Compressor
RLA/LRA
Blower
Motor
FLA/HP
Condenser
Motor
FLA/HP MCA
MOP/
MOCP
VHA09K
(230/208)
25RTQ 6.8 11.5/10.4 2450/2000 10.7/9.6
4.2/21
0.8 - 1/8 1.8 - 1/4
14.4 15
34RTQ 6.8 15.4/14.0 3350/2740 14.6/13.2 19.3 20
50RTQ 6.8 22.5/20.5 5000/4090 21.7/19.7 28.2 30
VHA09R
25RTQ 6.8 10 2450 9.2 12.5 15
34RTQ 6.8 13.4 3350 12.6 16.8 20
50RTQ 6.8 19.7 5000 18.9 24.7 25
VHA12K
(230/208)
25RTQ 7.3 11.5/10.4 2450/2000 10.7/9.6
4.7/23
14.4 15
34RTQ 7.3 15.4/14.0 3350/2740 14.6/13.2 19.3 20
50RTQ 7.3 22.5/20.5 5000/4090 21.7/19.7 28.2 30
VHA12R
25RTQ 7.3 10 2450 9.2 12.5 15
34RTQ 7.3 13.4 3350 12.6 16.8 20
50RTQ 7.3 19.7 5000 18.9 24.7 25
VHA18K
(230/208)
25RTQ 9.1 11.5/10.4 2450/2000 10.7/9.6
6.8/30
0.8 - 1/5
1.5 - 1/4
14.4 15
34RTQ 9.1 15.4/14.0 3350/2740 14.6/13.2 19.3 20
50RTQ 9.1 22.5/20.5 5000/4090 21.7/19.7 28.2 30
75RTQ 9.1 33.4/30.3 7500/6135 32.6/29.5 41.8 45
VHA18R
25RTQ 9.1 10 2450 9.2 12.5 15
34RTQ 9.1 13.4 3350 12.6 16.8 20
50RTQ 9.1 19.7 5000 18.9 25.3 30
75RTQ 9.1 29.1 7500 28.3 36.4 40
VHA24K
(230/208)
25RTQ 10.7 11.5/10.4 2450/2000 10.7/9.6
8.2/44
1.7 - 1/4
16 20
34RTQ 10.7 15.4/14.0 3350/2740 14.6/13.2 19.5 25
50RTQ 10.7 22.5/20.5 5000/4090 21.7/19.7 29.6 30
75RTQ 10.7 33.4/30.3 7500/6135 32.6/29.5 41.8 45
10RTQ 10.7 44.3/40.1 1000/8180 43.5/39.3 55.4 60
VHA24R
25RTQ 10.7 10 2450 9.2 15.3 20
34RTQ 10.7 13.4 3350 12.6 18.3 20
50RTQ 10.7 19.7 5000 18.9 27.1 30
75RTQ 10.7 29.1 7500 28.3 36.4 40
10RTQ 10.7 38.5 10000 37.7 48.2 50
NOTE: All units must be hard wired with a properly sized breaker. See unit nameplate for specic electrical requirements. Use HACR type breakers to avoid nuisance trips.
All eld wiring must be done in accordance with NEC and local codes. It is the installer’s responsibility that the electrical codes are met. The electrical requirement may
change without notice.
