21
Final Wall Plenum and Architectural Louver Installation
NOTE: Ensure that the weather strip is undamaged and provides a continuous
seal around the inner perimeter of the plenum.
Apply silicone grease or other non-petroleum-based lubricants to the weather strip to enhance the sealing capability of the
weather strip and ease installation of the air conditioner chassis.
1. Loosen the two set screws located on the top side of the divider.
2. Slide the top part of the divider toward the outside until the sealing strip makes contact with the exterior louver.
3. Tighten the set screws to complete the adjustment.
NOTE: Let all ashing cure completely before installing the chassis.
Louver
