SPECIFICATIONS
General Specications
Model VHA09K VHA09R VHA12K VHA12R VHA18K VHA18R VHA24K VHA24R
Cooling Data
Total Cap @
95˚F
9,000 8,800 11,000 11,000 17,600 17,400 21,800 21,600
Sensible Cap 6,650 6,650 8,100 8,100 12,500 12,500 15,400 15,000
SEER2 11.9 11.9 11.9 11.9 11.9 11.9 11.9 11.9
EER2 10.6 10.6 10.6 10.6 10.6 10.6 10.6 10.6
Heating Data
Total Cap @
47˚F
8200 8200 10,400 10,400 16,000 16,000 18,500 18,500
Cap @ 17˚F 4,500 4,500 5,600 5,600 9,000 9,000 12,000 12,000
COP2 3.1 3.1 3.1 3.1 3.1 3.1 3.1 3.1
HSPF2 6.3 6.3 6.3 6.3 6.3 6.3 6.3 6.3
Heater Sizes 2.5/3.4/5.0 2.5/3.4/5.0 2.5/3.4/5.0 2.5/3.4/5.0 2.5/3.4/ 5.0/7.5 2.5/3.4/ 5.0/7.5
2.5/3.4/5.0/
7.5/10.0
2.5/3.4/5.0/
7.5/10.0
Voltage 208/230 265 208/230 265 208/230 265 208/230 265
Other Data
Refrigerant R410a
Dimensions 23x23x32
Ventilation
CFM
Up to 70 CFM
Airflow (0.3”)
CFM
300 350 550 600
Table 105 ( general Specifications)
Electrical Requirements
ELECTRICAL REQUIREMENTS
SEE UNIT NAMEPLATE FOR SPECIFIC ELECTRICAL
REQUIREMENTS.
FUSE/CIRCUIT
BREAKER
USE ONLY TYPE AND SIZE FUSE OR HACR
CIRCUIT BREAKER INDICATED ON UNIT’S
RATING GUIDE. PROPER OVER CURRENT
PROTECTION TO THE UNITS IS THE
RESPONSIBILITY OF THE OWNER.
GROUNDING UNIT MUST BE GROUNDED FROM
BRANCH CIRCUIT TO UNIT, OR THROUGH
SEPARATE GROUND WIRE PROVIDED
ON PERMANENTLY CONNECTED UNITS.
ENSURE THAT BRANCH CIRCUIT
OR GENERAL PURPOSE OUTLET IS
GROUNDED.
WIRE SIZING ALL WIRING MUST COMPLY WITH LOCAL
AND NATIONAL CODES. NOTE: USE COPPER
CONDUCTORS ONLY. USE MINIMUM AMPACITY
RATINGS TO DETERMINE BRANCH CIRCUIT
WIRING SIZES.
WARNING
Electrical Shock Hazard.
Turn OFF electric power before service or instal-
lation.
Unit must be properly grounded.
Unit must have correct fuse or circuit breaker pro-
tection. Unit’s supply circuit must have the correct
wire conductor size. All electrical connections and
and conform to the National Electrical Code and all
local codes which have jurisdiction. Failure to do so
can result in property
damage, personal injury and/or death.

Friedrich VERT-I-PAK VHA18K34RTQ Specifications

General

Brand	Friedrich
Model	VERT-I-PAK VHA18K34RTQ
Category	Heat Pump
Language	English
