33 PB
COMPONENT IDENTIFICATION
Defrost Control Board
L2
Fan Out
Test
C
R D
B
Y
Outside
Ambient
Air
Sensor
Condenser
Coil
Sensor
Reversing
Valve
Low
Pressure
Switch
High
Pressure
Switch
Compressor
Out
Figure 602 (Defrost Control Board Identication)
