Friedrich VRP24K - Dimensions

5
Dimensions
Model VRP12K VRP12R VRP24K VRP24R
Dimensions (W x D x H) 26 1/8" x 25 1/8" x 52" 26 1/8" x 25 1/8" x 62"
Shipping Dimensions (W x D x H) 28 1/8" x 27 3/8" x 54 1/2" 28 1/8" x 27 3/8" x 64 1/2"
Net Weight (lbs.) 215 215 255 255
Shipping Weight (lbs.) 276 276 316 316
R410A Charge (oz.) 49.8 49.8 68.3 68.3
DUCT
FLANGE
VRP Dimensional Data 24K
VRP Dimensional Data 12K
