21
5.2.1 Upper Cabinet / Drum Heater
POS. NO DESCRIPTION
1 Panel, left side, white
3 Panel, top
4 Panel, rear, dryer, stainless
6 Clip, ball, steel, flat nut
8 Limiter, thermal, heater
9 Panel, motor access, washed
12 Bearing, drum support
13 Bracket, bearing support
14 Screw, bracket mtg. 10-16B x 1.375, cr/sq drive
15 # Housing, heater, gas
17 Baffle, heater shield
18 Screw, 10-16AB x 0.375
19 Cover, moisture sensor, assembly
19A Clip, end cap mtg, U-type
20 Glide, flat, dryer
21 Drum, LC GALV GD
22 Panel, Front, weld asmy LC Dr
22* Plug, light hole
22A Pin, panel locator
23 Seal, felt, lower
24 Seal, felt, upper
25 Door Catch, upper
26 # Switch, door
27 Lint Trap
29 Screw, quadrex head, 10-14 x 1.00, vane mtg. special
30 Vane, straight
31 Screw, 10-16AB x 0.625
32 Shaft, drum support, ball hitch
33 # Thermostat, safety
35 Screw, pan head, 8-18AB x 0.375
36 # Thermal Limiter
38 Panel, right side, white
39 Panel, access
41 Hinge, dryer door
42 Screw, flat head, 8-18AB x 0.44, quad drive
44 Gasket, door
46 Handle, door, white
