2. Connect the HOT inlet hose to the HOT inlet
connection on the washer and the COLD inlet hose to the
COLD inlet connection on the washer. Tighten by hand until
it fits properly. Then tighten each supply connection another
2/3 turns with pliers. Do not cross thread or over-tighten
these connections.
3. Connect the HOT inlet hose to the HOT water supply
and the COLD inlet hose to the COLD water supply. Tighten
by hand until it fits properly. Then tighten each supply
connection another 2/3 turns with pliers. Do not bend, kink
or pinch water inlet hoses.
4. Turn ON the water and check for leakages.
Connecting Vents
1. Remove the two screws (items A, to the right) securing
the front access panel of the dryer to the dryer cabinet. Lift
the panel until the tabs can be disengaged from the cabinet,
remove the panel and set aside.
2. Connect the exhaust duct to the outside exhaust
system. Use a 4”inches (10.2 cm) clamp (item B, to the right)
to connect the dryer to the exhaust vent system. Use metal
foil tape to seal all other joints.
3. Reinstall the front access panel of the dryer.
4. Carefully slide the Laundry Center to its final position.
Recheck for level and rock corners for stability.
