FRIGOMAT G5 G10 M04.37562 R.2021.10.23 ix
EN
IT
FR
DE
ES
TAV. 04
N. MOD. COD. DESCRIZIONE DESCRIPTION DESCRIPTION BESCHREIBUNBG DESCRIPCIÓN
1
G5 Z75.42724
Assieme trasmissione Transmission Assy Trasmission Übertragungsgruppe Grupo de transmisión
G10 Z75.42721
2 G5 G10 P10.072 OR 3068 OR 3068 OR 3068 OR 3068 OR 3068
3 G5 G10 L21.41892 Sede bronzina Bushing Housing Logement Douille Buchsengehäuse Asiento del buje
4 G5 G10 P10.067 OR 2087 OR 2087 OR 2087 OR 2087 OR 2087
5 G5 G10 A11.42009 Bronzina Bushing Douille Durchführungen Buje
6 G5 G10 L21.42251 Fermo bronzina Stop for Bushing Arrête pour Douille Halt für die Buchse Parada para buje
7
G5 L21.42726
Canotto Shaft Housing Carter d'arbre Wellengehäuse Carcasa del eje
G10 L21.41891
8 G5 G10 P21.41899 Trappola termica Insulating Flange Bride isolante Isolierflansch Brida aislante
9 G5 G10 A21.41900 Rasamento Spacer Espaceur Abstandshalter Espaciador
10 G5 G10 L21.37518 Ghiera Locking ring Bague de verrouillage Sicherungsring Anillo de bloqueo
11 G5 G10 L21.42723 Supporto Support Support Unterstützung Soporte
12 G5 G10 V14.073 Anello elastico Seeger Seeger Seeger Seeger
13 G5 G10 P02.42007 ORM 0250-10 ORM 0250-10 ORM 0250-10 ORM 0250-10 ORM 0250-10
14 G5 G10 P10.014 OR 2137 OR 2137 OR 2137 OR 2137 OR 2137
15 G5 G10 B14.036 Cuscinetto Bearing Roulement à billes Kugellager Cojinete
16 G5 G10 L21.41558 Distanziale Spacer Espaceur Abstandshalter Espaciador
17 G5 G10 V14.072 Anello elastico Seeger Seeger Seeger Seeger
18
G5 B60.42725
Albero trasmissione Shaft Arbre de trasmiss. Getriebewelle Eje de transmision
G10 B60.42722
G5 A01.43881
Piastra supporto Support Plate Plaque de support Stützplatte Placa de soporte
G10 A01.43762
20 G5 G10
E01.44235
Motore
(230V / 50Hz / 1ph)
Motor
(230V / 50Hz / 1ph)
Moteur
(230V / 50Hz / 1ph)
Motor
(230V / 50Hz / 1ph)
Motor
(230V / 50Hz / 1ph)
-
Motore
(220V / 60Hz / 1ph)
Motor
(220V / 60Hz / 1ph)
Moteur
(220V / 60Hz / 1ph)
Motor
(220V / 60Hz / 1ph)
Motor
(220V / 60Hz / 1ph)
E01.44518
Motore
(1150V / 60Hz / 1ph)
Motor
(1150V / 60Hz / 1ph)
Moteur
(1150V / 60Hz / 1ph)
Motor
(1150V / 60Hz / 1ph)
Motor
(1150V / 60Hz / 1ph)
21 G5 G10
E06.44545
Condensatore
(230V / 50Hz / 1ph)
Condenser
(230V / 50Hz / 1ph)
Condensateur
(230V / 50Hz / 1ph)
Kondensatorgang
(230V / 50Hz / 1ph)
Condensador
(230V / 50Hz / 1ph)
-
Condensatore
(220V / 60Hz / 1ph)
Condenser
(220V / 60Hz / 1ph)
Condensateur
(220V / 60Hz / 1ph)
Kondensatorgang
(220V / 60Hz / 1ph)
Condensador
(220V / 60Hz / 1ph)
-
Condensatore
(115V / 60Hz / 1ph)
Condenser
(115V / 60Hz / 1ph)
Condensateur
(115V / 60Hz / 1ph)
Kondensatorgang
(115V / 60Hz / 1ph)
Condensador
(115V / 60Hz / 1ph)
22 G5 G10 L06.37492 Puleggia motore Motor Pulley Poulie Moteur Motorrolle Polea del motor
23 G5 G10 V02.050 Perno Pin Goupille Stift Alfiler
24 G5 G10 A11.37495 Cuscinetto Bearing Roulement à billes Kugellager Cojinete
25 G5 G10 V13.006 Dado Nut écrou Mutter Tuerca
26 G5 G10 B65.37494 Tendicinghia Belt tightener Tendeur de couroie Riemenspanner Tensor de correa
27 G5 G10 L06.37493 Puleggia Pulley Poulie Riemensch. Polea
28 G5 G10 P10.37496 Cinghia Belt Courroie Gürtel Correa
29 G5 G10 A04.44232 Staffa Relè Relay Support Relays support Relaishalterung Soporte de relé
30 G5 G10 E08.44234 Relè Relay Relay Relais Relé
19
