Adjust the brake
Adjusting the
brake
NOTE!
After releasing the torch trigger the wirespool should stop unreeling.
Adjust brake if necessary.
1 2
3
Design of the
brake
CAUTION!
Risk of injury and damage from falling wirespool.
To ensure that the wirespool is properly in place and that the brake works properly, fit the
brake according to the following diagram.
