Working voltage
TIG 10.1 - 18.8 V
Electrode 20.4 - 27.2 V
Striking voltage (U
p
) 9.5 kV
The arc striking voltage is suitable for manual operation.
Degree of protection IP 23
Type of cooling AF
Insulation class B
EMC device class
(in accordance with EN/IEC 60974-10)
A
Dimensions L/W/H (with handle) 485 / 180 / 390 mm
19.1 / 7.1 / 15.4 in.
Weight (without handle) 17.4 kg
38.3 lb.
Weight (with handle) 17.8 kg
39.2 lb.
Mark of conformity S, CE
Idle state power consumption at 230 V 32.3 W
Power source efficiency at 180 A / 27.2 V 81%
MagicWave 2500
Comfort
Mains voltage 3 x 400 V
Mains voltage tolerance ± 15%
Grid frequency 50/60 Hz
Mains fuse protection (slow-blow) 16 A
Mains connection
1)
Z
max
on PCC
3)
= 122 mOhm
Primary continuous power (100% D.C.
2)
)
4.7 kVA
Cos phi 0.99
Welding current range
TIG 3 - 250 A
Electrode 10 - 250 A
Welding current at
10 min/40 °C (104 °F) 35% D.C.
2)
-
10 min/40 °C (104 °F) 40% D.C.
2)
250 A
10 min/40 °C (104 °F) 100% D.C.
2)
180 A
Open circuit voltage 89 V
Working voltage
TIG 10.1 - 20.0 V
Electrode 20.4 - 30.0 V
Striking voltage (U
p
) 10 kV
199
EN
