If the inverter is installed in a switch cabinet or a similar sealed area, then forced-air ven-
tilation must be provided to ensure adequate heat dissipation
If the inverter is to be installed on the outer wall of a cattle shed, maintain a minimum all-
round clearance of 2 m between the inverter and all ventilation and other openings in the
building.
The installation location must not be exposed to ammonia, corrosive vapours, salts or ac-
ids.

Fronius Primo Specifications

General

Category	Inverter
AC nominal output	3.0 - 8.2 kW
Grid frequency	50 Hz / 60 Hz
THD	< 3 %
Power factor (cos φac,r)	0.85 - 1 ind./cap.
Efficiency	98%
Max. input voltage	1000 V
MPP voltage range	240 - 800 V
Number of DC connections	2
Number of MPP Trackers	1
Dimensions (H x W x D)	645 x 431 x 204 mm
Weight	21.5 kg
Protection class	IP65
Operating temperature range	-40 °C to +60 °C
Warranty	5 years
Model	Primo
AC nominal voltage	230 V
