Before installation
Intended Use The cleaning device is used exclusively to mechanically clean Fronius robot weld-
ing torches in automatic mode within the limits of technical data, especially to
clean the gas nozzle and gas nozzle internal space. Any other use does not con-
stitute proper use. The manufacturer shall not be liable for any damage resulting
from such improper use.
Proper use also means
-
Reading these Operating Instructions in their entirety
-
Following all instructions and safety rules in these Operating Instructions
-
Carrying out all the specified inspection and servicing work
Operating per-
sonnel, mainten-
ance personnel
WARNING!
Danger due to machines starting automatically.
This can result in severe personal injury and damage to property.
▶
In all situations, the device must only ever be operated by one person. In ad-
dition, make sure that there are no other people in the device's operating
area while it is in operation.
▶
In all situations, the device must only ever be maintained by one person. In
addition, make sure that there are no other people in the device's operating
area while work on it is ongoing.
Setup regula-
tions
The cleaning device has been tested according to protection class IP 21. This
means:
-
Protection against solid foreign bodies larger than Ø 12.5 mm (0.49 in.)
-
No protection against penetrating water
The device should not be set up and operated outdoors. The installed electrical
components should be protected against direct exposure to moisture.
WARNING!
Danger from devices falling or toppling over.
This can result in severe personal injury and damage to property.
▶
Always screw the cleaning device to the surface.
Specifications
for the Com-
pressed Air Sup-
ply
To ensure the proper functioning of the cleaning device, fulfill the following spe-
cifications for the compressed air supply:
-
Set up a compressed air supply using the pressure relief valve and com-
pressed air filter
-
Guarantee the compressed air quality in accordance with ISO 8573-1:2001,
class 7 4 3, instrument air
-
Solid particle concentration £ 10 mg/m
3
-
Pressure concentration point vapor £ + 3°C
-
Oil concentration £ 1 mg/m
3
28
