2.3 Activating the Fronius Smart Meter on the GEN24 inverter
The web interface of the GEN24 can be reached in two ways:
1. Via Wi-Fi Access Point:
- Open the access point by pressing once on the sensor of the GEN24.
- Connect to the inverter's network
o Name: FRONIUS_Pilot Serial Number
o Password: 12345678
- Enter IP address 192.168.250.181 in the browser.
2. Via LAN connection:
- Connecting the computer to the inverter via LAN cable
o Use the LAN 1 port on the GEN24
- Open browser and enter IP address 169.254.0.180
When you access the dashboard, you must unlock the submenus with the technician password if this has not
already been done at start-up.
Open the "Configure Device" submenu and navigate to the "Components" menu. Here you can "add another
component".
Select whether the Smart Meter
is positioned at the feed-in point
or the consumption path.
