33
EN
IMPORTANT! In order for the logging function to work correctly the time must be set cor-
rectly.
Relays Activate relay, relay settings, relay test
* these are only shown if the 'E-Manager' function has been activated under 'Relay mode'.
Logging interval
Activate / deactivate the logging function and specify a logging interval
Unit Minutes
Setting range 30 min. / 20 min./ 15 min./ 10 min./ 5 min./ No log
Factory setting 30 min.
30 min. The logging interval is 30 minutes; every 30 minutes new log-
ging data will be saved on the USB stick.
20 min.
15 min.
10 min.
5 min. The logging interval is 5 minutes; every 5 minutes new logging
data will be saved on the USB stick.
No log No data is saved
Setting range Relay mode / Relay test / Switch-on point* / Switch-off point*
Relay mode
for selecting the different functions of the floating switch contact in the data communica-
tion area:
- Alarm function
- Active output
- Energy Manager
Setting range ALL / Permanent / OFF / ON / E-Manager
Factory setting ALL
Alarm function:
Permanent /
ALL:
Switch the floating switch contact for permanent and temporary ser-
vice codes (e.g. brief interruption to energy being fed into the grid, a
service code occurs a certain number of times a day - can be adjusted
in the 'BASIC' menu)
Active output:
ON: The floating NO contact is on all the time the inverter is in operation
(as long as the display is not dark or is displaying something).
OFF: The floating NO contact is off.
Energy Manager:
E-Manager: Further details on the 'Energy Manager' function may be found in the
"Energy Manager" section.
