Fronius Symo 15.0-3-M User Manual

41
EN
USB Stick as a Data Logger and for Updating Invert-
er Software
USB flash drive
as a datalogger
If a USB flash drive is connected to the USB A socket it can function as a datalogger for
an inverter.
At any time, the logging data stored on the USB flash drive can be
- imported into the Fronius Solar.access software using the FLD file that was logged at
the same time,
- viewed directly in third-party programs (e.g. Microsoft® Excel) using the CSV file
logged at the same time.
Older versions (before Excel 2007) are limited to a maximum of 65,536 rows.
Suitable USB
flash drives
Due to the variety of USB flash drives available on the market, it cannot be guaranteed that
every USB flash drive will be detected by the inverter.
Fronius recommends that only certified USB flash drives suitable for building sites are used
(look out for the USB-IF logo).
The inverter supports USB flash drives with the following file systems:
- FAT12
- FAT16
- FAT32
Fronius recommends that the USB flash drives employed should only be used for record-
ing logging data or updating the inverter software. The USB flash drives should not contain
any other data.
Further information on "Data on a USB flash drive", "Data volume and storage capacity"
as well as "Buffer memory" can be found at:
Fronius Symo 3 - 10 kW:
 http://www.fronius.com/QR-link/4204260172EN
Fronius Symo 10 - 20 kW, Fronius Eco:
 http://www.fronius.com/QR-link/4204260175EN

Fronius Symo 15.0-3-M Specifications

General

Max. efficiency	98.1%
Max. input voltage	1000 V
MPPT voltage range	200 - 800 V
Weight	34.8 kg
Protection rating	IP 66
Max. output current	21.7 A
AC nominal voltage	400 V
AC voltage range	320 - 480 V
Frequency	50 / 60 Hz
THD	< 3%
Number of MPP trackers	2
AC Frequency Range	50 / 60 Hz
Maximum Efficiency	98.1%
Warranty	5 years
AC nominal output	15000 W
Max. apparent AC power	15 kVA
Maximum AC Power	15000 VA
Maximum DC Power	22500 W
Operating Temperature Range	-25 to +60 °C
Max. input current	30 A
Max. input current (Idc max)	30 A
Cooling	Forced air cooling
