Fronius Symo 15.0-3-M User Manual

54
Technical data
Fronius Symo 3.0-3-S 3.7-3-S 4.5-3-S
Input data
MPP voltage range 200 - 800 V DC 250 - 800 V DC 300 - 800 V DC
Max. input voltage
(at 1,000 W/m² / -10 °C in an open circuit)
1000 V DC
Min. input voltage 150 V DC
Max. input current 16.0 A
Max. short circuit current of the solar mod-
ules (I
SC PV
)
24.0 A
Max. feedback current
4)
32 A (RMS)
5)
Output data
Nominal output power (P
nom
) 3000 W 3700 W 4500 W
Max. output power 3000 W 3700 W 4500 W
Nominal grid voltage 3~ NPE 400 / 230 V or 3~ NPE 380 / 220 V
Min. grid voltage 150 V / 260 V
Max. grid voltage 280 V / 485 V
Nominal output current at 220 / 230 V 4.5 / 4.3 A 5.6 / 5.4 A 6.8 / 6.5 A
Max. output current 9 A
Nominal frequency 50 / 60 Hz
1)
Total harmonic distortion < 3%
cos phi power factor 0.7 - 1 ind./cap.
2)
Power-up current pulse
6)
and duration 38 A / 2 ms
Max. output fault current per period 21.4 A / 1 ms
General data
Maximum efficiency 98%
European efficiency 96.2% 96.7% 97%
Overnight self-consumption < 0.7 W & < 3 VA
Cooling Controlled forced-air ventilation
Degree of protection IP 65
Dimensions h x w x d 645 x 431 x 204 mm
Weight 16 kg
Permissible ambient temperature - 25 °C - +60 °C
Permitted humidity 0 - 100%
EMC device class B
Overvoltage category DC / AC 2 / 3
Pollution level 2
Noise emission 58.3 dB(A) ref. 1pW
Protection devices
DC insulation measurement Integrated
Response to DC overload Operating point shift, power limitation
DC disconnector Integrated
RCMU Integrated

Fronius Symo 15.0-3-M Specifications

General

Max. efficiency	98.1%
Max. input voltage	1000 V
MPPT voltage range	200 - 800 V
Weight	34.8 kg
Protection rating	IP 66
Max. output current	21.7 A
AC nominal voltage	400 V
AC voltage range	320 - 480 V
Frequency	50 / 60 Hz
THD	< 3%
Number of MPP trackers	2
AC Frequency Range	50 / 60 Hz
Maximum Efficiency	98.1%
Warranty	5 years
AC nominal output	15000 W
Max. apparent AC power	15 kVA
Maximum AC Power	15000 VA
Maximum DC Power	22500 W
Operating Temperature Range	-25 to +60 °C
Max. input current	30 A
Max. input current (Idc max)	30 A
Cooling	Forced air cooling
