Fronius Symo 15.0-3-M User Manual

61
EN
Fronius Symo
dummy
Explanation of
footnotes
1) The values stated are defaults; the inverter is configured specifically to suit the re-
quirements of the relevant country.
2) Depending on the country setup or device-specific settings
(ind. = inductive; cap. = capacitive)
3) PCC = interface to the public grid
4) Maximum current from the inverter to the solar module when an error occurs in the
inverter
5) Guaranteed by the electrical configuration of the inverter
6) Current peak when switching on the inverter
Applicable stand-
ards and guide-
lines
CE mark
The devices comply with all the requisite and relevant standards and guidelines that form
part of the relevant EU Directive, and are therefore permitted to display the CE mark.
Circuit to prevent stand alone operation
The inverter has an approved circuit to prevent stand alone operation.
Grid failure
The standard measurement and safety procedures integrated into the inverter ensure that
in the event of a grid failure, the feed-in of energy is immediately interrupted (e.g. switch-
off by the energy supplier or damage to lines).
Input data Dummy 3 - 10 kW Dummy 10 - 20 kW
Nominal grid voltage 1 ~ NPE 230 V
Grid voltage tolerance +10 / -5 %
1)
Nominal frequency 50 - 60 Hz
1)
General data
Degree of protection IP 65 IP 66
Dimensions h x w x d 645 x 431 x 204 mm 725 x 510 x 225 mm
Weight 11 kg 22 kg

Fronius Symo 15.0-3-M Specifications

General

Max. efficiency	98.1%
Max. input voltage	1000 V
MPPT voltage range	200 - 800 V
Weight	34.8 kg
Protection rating	IP 66
Max. output current	21.7 A
AC nominal voltage	400 V
AC voltage range	320 - 480 V
Frequency	50 / 60 Hz
THD	< 3%
Number of MPP trackers	2
AC Frequency Range	50 / 60 Hz
Maximum Efficiency	98.1%
Warranty	5 years
AC nominal output	15000 W
Max. apparent AC power	15 kVA
Maximum AC Power	15000 VA
Maximum DC Power	22500 W
Operating Temperature Range	-25 to +60 °C
Max. input current	30 A
Max. input current (Idc max)	30 A
Cooling	Forced air cooling
