(8) "Shielding gas" button
For selecting the shielding gas used. The SP parameter is reserved for additional
shielding gases.
When the shielding gas is selected, the LED behind the corresponding shielding
gas lights up.
(9) "Wire diameter" button
For selecting the wire diameter used. The SP parameter is reserved for addi-
tional wire diameters.
When the wire diameter is selected, the LED behind the corresponding wire dia-
meter lights up.
(10) "Material" button
For selecting the filler metal used. The SP parameter is reserved for additional
materials.
When the material type is selected, the LED behind the corresponding filler metal
lights up.
(11) "Wire threading" button
Press and hold the button:
Gasless wire threading into the torch hosepack
While the button is being held, the wire drive operates at feeder inching speed.
(12) Gas-test button
For setting the required gas volume on the gas pressure regulator.
Tap the button once: shielding gas flows out
Tap the button again: shielding gas flow stops
If the Gas-test button is not tapped again, the shielding gas flow will stop after 30
s.
(13) SF - spot/stitch/SynchroPulse welding indicator
- Lights up if a value is set for the spot welding/stitch welding time (SPt) setup
parameter when spot welding or stitch welding mode is activated
- Lights up if a value is set for the Frequency (F) setup parameter when the
MIG/MAG synergic welding process is activated.
(14) Intermediate arc indicator
A spatter-prone "intermediate arc" occurs between the dip transfer arc and the
spray arc. The intermediate arc indicator lights up to alert you to this critical area.
(15) HOLD indicator
At the end of each welding operation, the actual values for welding current and
welding voltage are stored - the "HOLD" indicator lights up.
(16) Pulse indicator
Lights up when the MIG/MAG pulsed synergic welding process is selected
(17) Real Energy Input
For displaying the energy applied during the welding operation.
The Real Energy Input indicator must be activated in level 2 of the Setup menu –
33
EN-US
