(10) EASY DOCUMENTATION label
(11) TIG shielding gas connection socket
For the shielding gas supply for the (-) current socket (5)
Side view
No. Function
(1) Wirespool holder with brake
For holding standard wirespools
with a max. diameter of 300 mm
(11.81 in.) and a max. weight of 19
kg (41.89 lbs.)
(2) 4-roller drive
* Side panel not shown
38
