OPERATION
18
MTF--051059L
HOW TO USE THE WHEEL LOCKOUT
Each wheel is secured to the axle with a lockout pin. See
Figure 14. The unit was shipped with the lockout pin in the
locked position. For ease of maneuverability, disconnect the
lockout pin as follows.
1. Pull the knob out to disengage the lockout pin.
2. To lock in the disengaged position, turn the knob 1/4 turn
(90 degrees).
NOTE: Check tire pressure. See side of tire for maximum
inflation. Do not exceed listed maximum pressure.
Figure 14
Knob
Wheel Lockout
HOW TO SET THE DRIFT CUTTERS
(OPTIONAL ACCESSORY ON SOME MODELS)
Drift cutters are used to cut a path through snow deeper than
the auger housing.
1. Loosen the wingnuts that secure the drift cutters to the
auger housing (see Figure 15).
2. Raise the drift cutters to the desired height.
3. Tighten the wingnuts.
Drift Cutter
Wingnut
Figure 15
HOW TO USE THE HEATED GRIPS
Heated grips are designed for use when the
temperature is below 32 degrees. Do not turn
on electric grips if temperature is above 32 de-
grees.
When the temperature falls below 32 degrees, use the
heated grips to keep your hands warm. Move the heated grip
switch to the ON position (see Figure 13). It will take a couple
of minutes for the grips to become warm. Because heated
grips can become very warm, we recommend that you wear
gloves. If you notice that the grips are too warm, turn off
heated grips.

Table of Contents

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the Frontier ST1332 and is the answer not in the manual?

Frontier ST1332 Specifications

General IconGeneral
EngineBriggs & Stratton Intek Snow OHV
Horsepower13 hp
StarterElectric / Recoil
Fuel Capacity4 quarts
Drive SystemHydrostatic
SpeedsVariable Fwd/Rev
Traction ControlWheel Lock
Clearing Width32”
Auger Diameter16”
Auger TypeSteel / Saw Tooth
Impeller Diameter12”
Chute RotationElectric
Chute Turning Radius190
Deflector ControlRemote
Warranty - Engine3 years
Warranty - Machine3 years
Weight and Dimensions IconWeight and Dimensions
Tire Diameter16”
Housing Height23.5”
Weight307 lbs
