HIGH EFFICIENCY DECATHLON SERIES GAS FRYERS
CHAPTER 2: PARTS LIST
2-15
2.5 3” Oil Drain Manifold, Drain Flush, and Drain Valve Components (cont.)
ITEM PART # COMPONENT
1 823-5880 Drain Tube, Down Spout/Center Dump (SCFHD50)
* 823-5968 Drain Tube, Down Spout/Center Dump (FPHD65)
* 823-5881 Drain Tube, Down Spout/Center Dump (SCFHD60/80)
* 812-1802 Clamp, Down Spout Location
* 220-0873 Bracket, Drain Tube Location
2 823-4680 Drain Tube, Left (SCFHD50/60/80)
* 823-4844 Drain Tube, Left (SCFHD60)
3 823-4681 Drain Tube, Right (SCFHD50/60/80)
* 200-9365 Drain Tube, Right, Filter (FPHD65)
* 823-5188 Drain Tube, Right, Filter (SCFHD50/60/80)
4 200-6751 Drain Tube, Joiner (SCFHD50)
5 823-4682 Drain Tube, Joiner (SCFHD50/60/80)
6 809-0969 Clamp, T-bolt
7 816-0625 Boot/Sleeve
* 106-2568SP Wash Down Hose Assembly (includes handle and nozzle)
* 106-1837SP
Quick Disconnect, Female, with
1
⁄
2
" collar
* 813-0699
Quick Disconnect, Male,
1
⁄
2
"
* 810-1434
Hose Assembly, 66", with both ends
1
⁄
2
" NPT
* 106-1454SP Nozzle Assembly, with handle
* 106-2387 Heater Strip 120V, 25W, 36”, with 2-pin male connector
Flush Oil Drain Line
8 813-0686
Bell Reducer, 1
1
⁄
2
" x
1
⁄
2
"
9 813-0165
Elbow, Street
1
⁄
2
" x
1
⁄
2
" NPT 90° BM
10 810-1669
Adapter, Female
5
⁄
8
" O.D. x
1
⁄
2
" Long
11 810-1668
Adapter, Male
5
⁄
8
" O.D. x
1
⁄
2
" Long
12 810-1056
Flexline,
5
⁄
8
" O.D. x 52.5" Long
106-3976
Drain Valve Assembly, 1
1
⁄
2
" without Microswitch
106-3977
Drain Valve Assembly, 1
1
⁄
2
" with Microswitch
13 810-2783
Drain Valve, 1
1
⁄
2
" Full Port with O-ring
* 816-0544 O-ring Seal
14 823-4734 Handle, Drain Valve Rotating
15 807-2104 Microswitch, CE Micro-roller Lever
16 106-5511 Microswitch Bracket Assembly
17 220-0143 Guard, Drain Microswitch
18 816-0220 Insulation, RF Switch
19 816-0547 Cap, Red Vinyl for Handle
20 200-6116
Strap, 1
1
⁄
2
" (holds tube to valve via the stud)
21 809-0988 Washer, Drain Microswitch, Teflon
22 200-1257 Retainer, Drain Valve
23 826-1366 Nut, 4-40 Keps Hex w/External Teeth (pkg. of 25)
* 816-0665 Cap, Vinyl (one per clamp, covers T-bolt threads)
* Not illustrated.
