HIGH EFFICIENCY DECATHLON SERIES GAS FRYERS
CHAPTER 2: PARTS LIST
2-17
2.6 Oil Return Manifold Components (cont.)
ITEM PART # COMPONENT
106-4080 Oil Return Manifold, End (SCFHD50)
106-5616 Oil Return Manifold (SCFHD250)
106-4101 Oil Return Manifold, End (SCFHD60)
KIT9342 Oil Return Manifold (SCFHD260)
106-6468 Oil Return Manifold, #1 (FPHD)
106-6469 Oil Return Manifold, #3 (FPHD)
106-6471 Oil Return Manifold, #4 (FPHD)
106-6470 Oil Return Manifold, #1, #2, #5, #6 (FPHD)
106-5499
Oil Return Manifold, Chili's (SCFHD460)
1 106-4006SP
Valve Assembly,
1
⁄
2
" Oil Return (see Section 2.7)
* 106-3997 Valve Assembly (use with wand)
106-6797 Valve Assembly, 3-way Oil Return, Over-the-Top (FPHD, non-C/C)
2 210-9643 Spring Clip
3 210-9915 Cover, Dean Oil Return Microswitch
4 210-9916 Support, Dean Microswitch Mount
5 807-2104 Switch, CE Micro Roller Lever
6 809-0045 Nut, Cap 10-32 Hex
7 809-0056 Nut, 5/16-18 Hex
8 809-0117 Screw, 10-32 x 3/8 Slotted Truss Head
9 809-0237 Nut, 4-40 Keps Hex w/ Extended Teeth
10 809-0256 Nut, Keps 10-32 Hex
11 809-0354 Screw, 4-40 x ¾ Round Head
12 809-0942 Washer, 5/16 Belleville, 18-8
13 810-1003 180°, 3-way Ball Valve
14 816-0220 Insulation, Switch
15 106-5229 Support, Oil Return Valve
16 823-5952 Handle, 3-way Valve (FPHD; FPHD565 uses 823-5363)
17 810-1668
Adapter, Male
5
⁄
8
" OD x
1
⁄
2
"
18 810-1067 Flexline, 8.5” Oil Return
* 810-1055 Flexline, 11.5” Oil Return
* 810-1056 Flexline, 52.5” Oil Return
* 810-1069 Flexline, 29.50" Oil Return
19 813-0003
Tee,
1
⁄
2
" x
1
⁄
2
" x
1
⁄
2
" BM
20 813-0022
Nipple,
1
⁄
2
" x Close NPT BM
21 813-0099
Nipple,
1
⁄
2
" x 7.00" NPT BM
22 813-0165
Elbow, Street
1
⁄
2
" x
1
⁄
2
" NPT 90° BM
23 813-0173
Union,
1
⁄
2
" NPT
24 813-0247
Nipple,
1
⁄
2
" x 3.50" NPT BM
25 813-0362
Nipple,
1
⁄
2
" NPT x 7.50" BM
26 813-0463
Plug,
1
⁄
2
" Counter Sink
27 813-0661
Nipple,
1
⁄
2
" x 2.25" NPT BM
28 813-0654
Nipple,
1
⁄
2
” x 4.00” NPT BM
29 813-0597
Nipple,
1
⁄
2
“ x 11.50” NPT BM
* 813-0062
Elbow,
1
⁄
2
", 90° BM
* 813-0087
Nipple,
1
⁄
2
" x 1.50" NPT BM
* 813-0460
Nipple,
1
⁄
2
" x 3.00" NPT BM
* 813-0672
Nipple,
1
⁄
2
" x 8.00" NPT BM
* 813-0607
Nipple,
1
⁄
2
" x 23.5” NPT BM
* 813-0646
Nipple,
1
⁄
2
" x 5.00" NPT BM
* 813-0373
Nipple,
1
⁄
2
" x 11.00" NPT BM
