HIGH EFFICIENCY DECATHLON SERIES GAS FRYERS
CHAPTER 2: PARTS LIST
2-20
2.7 Oil Return and Oil Flush Components (cont.)
ITEM PART # COMPONENT
106-4006SP
Microswitch Bracket Assembly, Oil Return
1 901-2772 Handle, RF Left
2 900-2935 Retainer, Nut
3 816-0220 Insulation, RF Switch
4 810-0278
Ball Valve,
1
⁄
2
" Oil Return
5 826-1366 Nut, 4-40 Keps Hex w/External Teeth (pkg. of 25)
6 807-2103 Microswitch, Straight Lever (CE)
7 200-6806 Cover, Safety Switch
8 106-3962 Bracket Assembly, RF Switch
Oil Suction Assembly
9 813-0062 Elbow, 90° BM
10 813-0173
Union,
1
⁄
2
" NPT 150# BM
11 813-0654
Nipple, TBE
1
⁄
2
" NPT x 4" Black
12 813-0674
Nipple, TBE
1
⁄
2
" NPT x 7
1
⁄
4
" Black
13 200-1230 Bracket, Front Male Manifold
106-0774SP
Suction Manifold Assembly
14 810-0697 Disconnect, Male Suction Tube
* 826-1392 O-rings, for Male Disconnect (pack of 5)
15 813-0608
Coupling,
1
⁄
2
" NPT BM Full
16 823-3188 Suction Manifold
106-0858
Oil Suction Start Fitting
17 813-0022
Nipple,
1
⁄
2
" NPT x Close
18 813-0463
Plug,
1
⁄
2
" Counter Sink
19 813-0003
Tee,
1
⁄
2
" NPT BM
* 210-8790 Bracket, Oil Return/Flush Retainer
* 200-8929 Handle, Oil Return
* 200-9850 Handle, Oil Return (Application Series “DF” fryers)
* 816-0638 Cap, Oil Return Handle, Yellow
* 816-0637 Cap, Oil Return Handle, Blue
Pump and Motor
20 807-3859 Motor (HD50/60 C/C, HD63, FPHD65)
* 810-2100 Motor (HD50/60, non-C/C)
21 810-3071 Pump, 8GPM (Viking, C/C)
22 810-2098 Pump, 8GPM (Dean, non-C/C)
* 810-2716 Pump, 2-piece 4GPM (Viking, HD56)
* Not illustrated.
