HIGH EFFICIENCY DECATHLON SERIES GAS FRYERS
CHAPTER 2: PARTS LIST
2-25
2.9 Basket Lift Components (cont.)
ITEM PART # COMPONENT
106-1870 Basket Lift Assembly (HD60)
1 823-3625 Basket Lift
2 809-0082 Truarc Ring,
3
/
4
"
3 200-2735 Channel, Support Autolift
4 200-2069 Member, Lift Control Arm
5 810-2140 Bushing (Oiltite)
3
⁄
8
" x
1
⁄
2
"
6 813-0035 Bushing (Bronze), .641/.640 ID
7 824-0958 Back, Basket Lift Motor (D60)
8 824-0959 Cover, Basket Lift Motor (D60)
9 200-1376 Bracket, Restraining
10 106-1463 Motor Assembly
* 200-1693 Plate, Motor Mounting
* 807-0107 Gear Motor
* 807-2104 Microswitch, CE Roller
* 807-3546 Bushing, Heyco, 750-625 (
3
/
4
")
* 810-2144 Spacer, Aluminum,
1
⁄
4
" OD x
3
⁄
8
" L, #4-40
11 823-3626 Switch, Limit Cam
Motor Housing
12 200-2736 Housing, Front
13 200-2739 Housing, Bottom
14 200-2364 Housing, Back
15 807-0140 Connector,
3
⁄
8
"
16 823-5904 Left Basket Lift Arm
17 823-5905 Right Basket Lift Arm
18 823-3500 Basket Lift Guide Plate (HD60)
* Not illustrated.
