2.2 Power Requirements
The three-phase supply plug for the elements is rated at 60 amps, 250 VAC and is NEMA configuration L15-60P. The
control and filter plug is rated at 20 amps, 120/208 VAC and is NEMA configuration L21-20P. Each fryer should have
its cord for the element supply on an individual circuit as well as the control cord.
VOLTAGE PHASE
WIRE
SERVICE
MIN.
SIZE
AWG
(mm
2
)
AMPS PER LEG
L1 L2 L3
208 3 3 6 (16) 39 39 39
240 3 3 6 (16) 34 34 34
480 3 3 8 (10) 17 17 17
220/380 3 4 6 (16) 21 21 21
240/415 3 4 6 (16) 20 20 21
230/400 3 4 6 (16) 21 21 21
NOTICE
If this appliance is permanently connected to fixed wiring, it must be connected by means of copper wires
having a temperature rating of not less than 167°F (75°C).
DANGER
This appliance must be connected to a power supply having the same voltage and phase as specified on the
rating plate located on the inside of the appliance door.
DANGER
All wiring connections for this appliance must be made in accordance with the wiring diagram(s) furnished
with the appliance. Refer to the wiring diagram(s) furnished with the appliance when installing or servicing
this equipment.
2.3 After Fryers Are Positioned at the Frying Station
DANGER
No structural material on the fryer should be altered or removed to accommodate placement of the fryer
under a hood. Questions? Call the Frymaster Service Hotline at 1-800-551-8633.
1. Once the fryer has been positioned at the frying station, use a carpenter’s level placed across the top of the
frypot to verify that the unit is level, both side-to-side and front-to-back.
To level fryers, adjust the casters being careful to ensure the fryer(s) are at the proper height in the frying
station.
The front right caster may be locked with setscrews that may need to be loosened to move into place. Once in
place, the caster setscrews can be locked with the caster wheel parallel to the fryer from front to back to ease
moving the fryer in and out of the hood for cleaning and preventing the caster from hitting the oil reservoir.
When the fryer is leveled in its final position, install the restraints provided by the KES to limit its movement so
that it does not depend on or transmit stress to the electrical conduit or connection. Install the restraints in
accordance with the provided instructions. If the restraints are disconnected for service or other reasons, they
must be reconnected before the fryer is used.
DANGER
Adequate means must be provided to limit the movement of this appliance without depending on or
transmitting stress to the electrical conduit. A restraint kit is provided with the fryer. If the restraint kit is
missing contact your local Frymaster Authorized Servicer (FAS).
