Frymaster H14 Series - Operating Fryers With Digital Controllers

3–12
3.4 Operating Fryers With Digital Controllers
5 6 7 8
4 3 12
ITEM DESCRIPTION
1 Lighted Display – right side display of various functions and operations.
2 Lighted Display – left side display of various functions and operations.
3 On/Off Switch - controls power supply.
4 C/F Switch - selects temperature display in Celsius or Fahrenheit.
5 Temperature/Setpoint Display Switch - selects cooking oil/shortening temperature or
setpoint temperature.
6 Up Arrow Switch - raises setpoint temperature.
7 Down Arrow Switch - lowers setpoint temperature for left side of split-pot and for full-pot.
8 Melt-Cycle Switch - cancels melt-cycle mode.
