FS S3410 Series

USB
CONSOLE
Reserved
An RJ45 console port for serial management
S3410-48TS-P
CONSOLE
USB RJ45 RJ45/SFP Combo
SFP+
Ports Description
RJ45
RJ45/SFP Combo
SFP+
10/100/1000BASE-T ports for Ethernet connection
One RJ45 port and one SFP slot, with one port active at a time
SFP+ ports for 1/10G connection
S3410-24TS-P
CONSOLE
USB RJ45 RJ45/SFP Combo SFP+
PoE
STATUS M1 M2 PWR1 PWR2 PoE
1 2 3 4 5 6 7 8 9 10 11 12 13 14 15 16 17 18 19 20
21 22
23 24
24 25 2623
Green=1000M Yellow=10/100M On=Link Flashing=ACT PoE LED:Green=Good Supply Yellow=Over Load
CONSOLE
SFP+
S3410-24TS-P PoE+
