multitronic
881/881GL/ServoAccess
Principle of connection
Rail-mounted mains adapter
Input voltage 100 - 240 VAC
Output voltage 12 VDC
Voltage regulator 10.8-13.8 VDC
881-control unit‘s circuit
board with radio receiver
black
white
red
Cable from the
motor-driven lock
Junction box with 4 cable
feeds, dimensions:
H200xB112xT94
13 14 15 16 17
13
14
15
1
2
345
6
7
8
91011
12
