Fuji Electric Micro-Controller X Socket type Instruction Manual

86(5NH\DVVLJQPHQW
8N<WRVHWYDOXH Key function
0 No function
1 6ZLWFKRYHUEHWZHHQ67%<212))
2 6ZLWFKRYHUEHWZHHQ$XWR0DQXDO
3 6ZLWFKRYHUEHWZHHQ/RFXO5HPRWH
4 Setting unavailable
5 Starts AT (standard)
6 6WDUWV$7ORZ39
7 Setting unavailable
8 5DPS69+2/'
9 Ramp soak RUN/OFF
10 5DPSVRDN581+2/'
11 Setting unavailable
12 /DWFKUHOHDVHDOO
13 /DWFKUHOHDVH$/0
14 /DWFKUHOHDVH$/0
15 /DWFKUHOHDVH$/0
19 6WDUWWLPHU$/0
20 6WDUWWLPHU$/0
21 6WDUWWLPHU$/0
25 SVNo. + 1 (send)
26 PID No. + 1 (send)
27 Setting unavailable
28 Ramp soak pattern No. + 1 (send)
29 SV No. + 1, PID No. + 1 (send)
287$ODUPRXWSXWLQGLFDWRUVDVVLJQPHQW
OUT
(Relay/SSR)
OUT
(Current/
Voltage)
Alarm output Indicator
Category Function
oU1T, oU2T oU1T, oU2T
do1T, do2T,
do3T
/R8/R8
/(9WR
/67E/0$1
0 0 0 0 None
1 1 1 1 Control output MV1 (heating)
2 2 2 2 MV2 (cooling)
3 — 3 3 Alarm output Alarm 1
4 — 4 4 Alarm 2
5 — 5 5 Alarm 3
10 — 10 10 Status output During auto-tuning startup
11 — 11 11 Normal operation
12 — 12 12 Standby
13 — 13 13 During manual mode
14 — 14 14 During remote SV operation
15 — 15 15 During ramp SV
16 — 16 16 System error
20 — 20 20 Ramp soak
event output
OFF
21 — 21 21 RUN
22 — 22 22 +2/'
23 — 23 23 GS (Guaranty soak)
24 — 24 24 END
110 — 110 110 Alarm indicator
output
Alarm 1 indiator output
111 — 111 111 Alarm 2 indiator output
112 — 112 112 Alarm 3 indiator output
170 — 170 170 Ramp soak
Time signal
Time signal (step 1 ramp)
171 — 171 171 Time signal (step 1 soak)
172 — 172 172 Time signal (step 2 ramp)
173 — 173 173 Time signal (step 2 soak)















294 — 294 294 Time signal (step 63 ramp)
295 — 295 295 Time signal (step 63 soak)
296 — 296 296 Time signal (step 64 ramp)
297 — 297 297 Time signal (step 64 soak)
300 — 300 300 Ramp soak
Relative time
signal
Time signal (1st step ramp)
301 — 301 301 Time signal (1st step soak)
302 — 302 302 Time signal (2nd step ramp)
303 — 303 303 Time signal (2nd step soak)















424 — 424 424 Time signal (63rd step ramp)
425 — 425 425 Time signal (63rd step soak)
426 — 426 426 Time signal (64th step ramp)
427 — 427 427 Time signal (64th step soak)
- 21 -
