Fuji Electric Micro-Controller X Socket type Instruction Manual

'LJLWDOLQSXW',IXQFWLRQ
YoucanallocateoneofthefollowingfunctionstoeachofDI1,DI2,andDI3.ThesefunctionsareactivatedbyexternalDIsignals.
No. Function Action ON OFF Criteria
0 No function No action — — —
1 6WDQGE\212))VZLWFKRYHU 6ZLWFKHVEHWZHHQ6WDQGE\212)) Standby Cancels Standby Edge
2 $XWRPDQXDOVZLWFKRYHU 6ZLWFKHVWKHFRQWURORXWSXWDFWLRQEHWZHHQDXWRPDQXDO Manual Auto Edge
3 /RFDOUHPRWHVZLWFKRYHU 6ZLWFKHV69EHWZHHQORFDOUHPRWH Remote /RFDO Edge
4 No function Not for use. — — —
5 Auto tuning (standard) start Runs standard auto-tuning. Start Stop Edge
6 $XWRWXQLQJORZ39VWDUW 5XQVORZ39W\SHDXWRWXQLQJ Start Stop Edge
7 Ramp SV ON/OFF Enables or disables ramp SV. Disable Enable Edge
8 Ramp SV hold 6ZLWFKHVEHWZHHQUDPS69KROGDQGKROGFDQFHO Hold Hold cancel Edge
9 Ramp soak RUN/OFF 6ZLWFKHVEHWZHHQUDPSVRDN5812)) RUN OFF Edge
10 5DPSVRDN581+2/' 6ZLWFKHVEHWZHHQUDPSVRDN581+2/' RUN +2/' Edge
11 No function Not for use. — — —
12 Unlatch (all) Cancels all the alarm latches. Unlatch — Edge
13 Unlatch (alarm 1) Unlatches the alarm 1.
14 Unlatch (alarm 2) Unlatches the alarm 2.
15 Unlatch (alarm 3) Unlatches the alarm 3.
16 No function Not for use. — — —
17 No function Not for use. — — —
18 No function Not for use. — — —
19 Timer (alarm 1) Runs the timer for the alarm 1. Timer ON Timer OFF /HYHO
20 Timer (alarm 2) Runs the timer for the alarm 2.
21 Timer (alarm 3) Runs the timer for the alarm 3.
22 No function Not for use. — — —
23 No function Not for use. — — —
24 No function Not for use. — — —
25 SV No. + 1 Increases the SV number by 1. +1 — /HYHO
26 SV No. + 2 Increases the SV number by 2. +2 — /HYHO
27 SV No. + 4 Increases the SV number by 4. +4 — /HYHO
28 PID No. + 1 Increases the PID number by 1. +1 — /HYHO
29 PID No. + 2 Increases the PID number by 2. +2 — /HYHO
30 PID No. + 4 Increases the PID number by 4. +4 — /HYHO
31 SV No. + 1,
PID No. + 1
Increases both the SV number and PID number by 1. +1 — /HYHO
32 SV No. + 2,
PID No. + 2
Increases both the SV number and PID number by 2. +2 — /HYHO
33 SV No. + 4,
PID No. + 4
Increases both the SV number and PID number by 4. +4 — /HYHO
34 Ramp soak OFF Stops ramp soak operation. OFF — Edge
35 Ramp soak RUN Runs ramp soak. RUN — Edge
36 5DPSVRDN+2/' Holds ramp soak. +2/' —Edge
37 Pattern No. + 1 Increases the pattern number by 1. +1 — /HYHO
38 Pattern No. + 2 Increases the pattern number by 2. +2 — /HYHO
39 Pattern No. + 4 Increases the pattern number by 4. +4 — /HYHO
40 Pattern No. + 8 Increases the pattern number by 8. +8 — /HYHO
41 DI soft start Starts DI soft start. Start — Edge
42 No function Not for use. — — —
43 Delay start (alarm 1) (QDEOHVGHOD\VWDUWZLWKWKHGHOD\WLPH G/< Delay start enable —
44 Delay start (alarm 2) (QDEOHVGHOD\VWDUWZLWKWKHGHOD\WLPH G/< Delay start enable —
45 Delay start (alarm 3) (QDEOHVGHOD\VWDUWZLWKWKHGHOD\WLPH G/< Delay start enable —
46 No function Not for use. — — —
47 No function Not for use. — — —
48 No function Not for use. — — —
- 22 -
