Fuji Xerox DocuPrint CP105 b - Toner Cartridge Replacement

Maintenance 160
 Cleaning the Color Toner Density (CTD) Sensor
Clean the CTD sensor only when an alert for the CTD sensor is shown on the Status Monitor window
or operator panel.
1 Ensure that the printer is turned off.
2 Push the rear cover handle and open the rear door.
3 Clean the CTD sensor inside the printer with a clean dry cotton swab.
4 Close the rear door.
