Features
2 - English A26361-D1218-Z180-1-7619
Features
The table shows two assembly versions of this system board as example.
Function Version D1218-A1X Version D1218-B1X
Processor socket PGA 370 PGA 370
Processor Intel Celeron or Pentium III Intel Celeron or Pentium III
Formfactor ATX ATX
Front Side Bus in MHz 66/100/133 66/100/133
Chipset 815e 815e
Memory sockets 3 DIMM 3 DIMM
PCI slots 5 5
AGP Port 1 1
CNR slot Type A - - 1
System monitoring - - - -
Thermal Management - - - -
Wake On LAN x x
Basic Alert On LAN II - - - -
Chipcard reader x x
Save to Disk (ACPI S4) x x
Save to RAM(ACPI S3) x x
Game/midi port x x
LAN onboard Ethernet Contr. 82562ET Ethernet Contr. 82562ET
Audio onboard AD1885 AD1885
VGA onboard i 815 i 815
USB ports extern 2 2
USB ports intern 2 1 - internal connector
1 - via CNR connector
